Gaming
- Colorshift Fan with 6 color changing pattern for optimal gaming experience
Glittering
–Three enlarged color shifting fans creates most eye catching appearance
Gradational
- Adjustable fan speed control for performance mode or silent mode
Gigantic
- Massive storage capability with 7 x 3.5”and 2 x 2.5 HDD or SSD bay
Glaciated
- Excellent thermal performance with glacial airflow
|
Patent Information
|
|
|---|---|
|
Country
|
Patent No.
|
|
Taiwan
|
D131551
|
|
China
|
1094606
|
| P/N | VL10001W2Z |
|---|---|
| Séries | Autres |
| Model | VL10001W2Z |
| TYPE DE BOITIER | Middle Tower |
| DIMENSIONS (H x L x P) | 480.0 x 230.0 x 521.0 mm (18.9 x 9.1 x 20.5 inch) |
| POIDS NET | 7.92 kg / 17.46 lb |
| PANNEAU LATÉRAL | Mesh Window |
| COULEUR | Exterior & Interior : Black |
| MATÉRIEL | Front bezel: Metal mesh Chassis: SECC |
| SYSTÈME DE REFROIDISSEMENT | Front (intake) : 200 x 200 x 20 mm Touchcolor fan, 600~800rpm, 12~14dBA; Two 120 x 120 mm fan (optional) Rear (exhaust) : 140 x 140 x 25 mm TurboFan, 1000rpm, 16dBA Top (exhaust) : 200 x 200 x 20 mm Touchcolor fan, 600~800rpm, 12~14dBA VGA (exhaust) : Two 60 x 60 mm fan (optional) Side (intake) : Plug&Play 230 x 230 x 20 mm Touchcolor fan, 600~800rpm, 13~15dBA |
| BAIES DE LECTEUR | 12 - Accessible : 3 x 5.25’’ - Hidden : 7 x 3.5’’, 2 x 2.5” |
| FENTES D'EXTENSION | 7 |
| CARTES MÈRES | 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) |
| LCS Upgradable | Support 1/2”、3/8”、1/4” water tube |
| PORT E/S | USB 2.0 x 4, HD Audio |
| Bloc Alimentation | Standard ATX PSII (optional) |
